MK Clamping Element

STOCK ITEM
Pneumatic Clamping element, designed to be used for holding a position when using Linear Rail Guides.
Energize to close (NO).
More types are available, contact Rollco for further information.


Dimensions in mm.

Product Information

Temperature: -10 - 70°C
Designation Select all Lead Time * Fixing force (N) Operating pressure (bar) Max. operating pressure (bar) Installation way
/storage/816236F9BBE647E4303A4ED9ED67C06B3CD6F28ABA8EA732433A2EB3C9D9134E/51a54b271d7946e2a2c029b71a4e14dc/stp/media/303dd5e1d36d445980a6841fbe5882e3/Clamping-element-MK1501A-Rollco.stp 1 650 6 6,50 from above
/storage/599E5898821CC5C0A2FC898739CD39106E253B9B98445D3FD7D2957BBE0D77B6/9436783e4336498b836ec30eecbc31c3/stp/media/061b159527134614a1823d6c69a29a50/Clamping-element-MK2001A-Rollco.stp 1 1000 6 6,50 from above
/storage/029902E8A03A43BE6E735AF6B4FE26D3BB8F8EEFB6ADF8D77A052C6892E73E74/b158e89b9a19413fb2217a3b157404d6/stp/media/3699ab4b298c47b4b925923537a9ab84/Clamping-element-MK2501A-Rollco.stp 1 1200 6 6,50 from above
/storage/081C8EE52DFB0A5281356D0B7620741ECD8E03774FEDD8871C197B7642B0E4C3/032eb18c7ff849f592190f3512eaa2fe/stp/media/2ff3b561202f4de8a62c108411394001/Clamping-element-MK3001A-Rollco.stp 2 1750 6 6,50 from above
/storage/8F527D84FD1A32C982ED1432FAF0A4160D9C41D179D9B53DF47D31A0E0485F89/4de22807293a45e79aee395c6e4e4592/stp/media/ee81d9ca8e9f454f8a0167e07a7667f0/Clamping-element-MK3501A-Rollco.stp 2 2000 6 6,50 from above
/storage/2F5E33D95E53A3B1921EF33A765CB89AB6AD6237D3E0FA4BAE3655E513C1CD0F/4509cb32914645f2a8d13979fe900dab/stp/media/04d1caaaa50949d980530a8cf68089fe/Clamping-element-MK4501A-Rollco.stp 2 2250 6 6,50 from above
/storage/7BB73001468FA83116D5B6CD945061431B1293D58B5AE0BBEF98A3855F735E9F/1a0a6004430a4180826f5fa60476921d/stp/media/30ac03dc0da04f9bb93c7d9d05ba66a2/Clamping-element-MK5501A-Rollco.stp 2 2250 6 6,50 from above
/storage/DF31DC0C4C0A1DBF9FC6FCB2CF80A0129092F698A764E456E04487F682D2ABBE/8a589401da4a42ea8c783cc7de9318ea/stp/media/536a7752160649139ba057c99c88c459/Clamping-element-MK6501A-Rollco.stp 2 2250 6 6,50 from above

*Green: Stock item, normally immediate shipment. Blue: Contact us for delivery time.

Designation Select all OW D T A B1 C X E A1 A2 B2 B3 G H F W1 (SW air filter) G1 (air connection) X1 (air filter horizontal / mm) Y1 (air filter vertical / mm) Y2 (air connection vertical / mm)
/storage/816236F9BBE647E4303A4ED9ED67C06B3CD6F28ABA8EA732433A2EB3C9D9134E/51a54b271d7946e2a2c029b71a4e14dc/stp/media/303dd5e1d36d445980a6841fbe5882e3/Clamping-element-MK1501A-Rollco.stp 15 24 0 55 39 2,50 24 21,50 15 5 15 15,50 M4 4,50 8 7 M5 34 17 6,10
/storage/599E5898821CC5C0A2FC898739CD39106E253B9B98445D3FD7D2957BBE0D77B6/9436783e4336498b836ec30eecbc31c3/stp/media/061b159527134614a1823d6c69a29a50/Clamping-element-MK2001A-Rollco.stp 20 28 0 66 39 2,50 28 25,50 20 6 20 5 M5 5,50 8 7 M5 34 6 6
/storage/029902E8A03A43BE6E735AF6B4FE26D3BB8F8EEFB6ADF8D77A052C6892E73E74/b158e89b9a19413fb2217a3b157404d6/stp/media/3699ab4b298c47b4b925923537a9ab84/Clamping-element-MK2501A-Rollco.stp 23 36 2 75 35 6 34 28 20 5 20 5 M6 8 8 7 M5 34 4,70 4,70
/storage/081C8EE52DFB0A5281356D0B7620741ECD8E03774FEDD8871C197B7642B0E4C3/032eb18c7ff849f592190f3512eaa2fe/stp/media/2ff3b561202f4de8a62c108411394001/Clamping-element-MK3001A-Rollco.stp 28 45 3 90 39 7 42 35 22 5 22 8,50 M8 10 8 7 M5 24,50 5,20 5,20
/storage/8F527D84FD1A32C982ED1432FAF0A4160D9C41D179D9B53DF47D31A0E0485F89/4de22807293a45e79aee395c6e4e4592/stp/media/ee81d9ca8e9f454f8a0167e07a7667f0/Clamping-element-MK3501A-Rollco.stp 34 48 4 100 39 7,50 44 36,50 24 5 24 7,50 M8 10 8 7 M5 20 5,20 5,20
/storage/2F5E33D95E53A3B1921EF33A765CB89AB6AD6237D3E0FA4BAE3655E513C1CD0F/4509cb32914645f2a8d13979fe900dab/stp/media/04d1caaaa50949d980530a8cf68089fe/Clamping-element-MK4501A-Rollco.stp 45 60 6 120 49 10,50 54 43,50 26 5 26 11,50 M10 15 8 7 M5 29,50 11 11
/storage/7BB73001468FA83116D5B6CD945061431B1293D58B5AE0BBEF98A3855F735E9F/1a0a6004430a4180826f5fa60476921d/stp/media/30ac03dc0da04f9bb93c7d9d05ba66a2/Clamping-element-MK5501A-Rollco.stp 53 70 6 128 49 15,50 64 48,50 30 5 30 9,50 M10 18 8 7 M5 29,50 14,50 14,50
/storage/DF31DC0C4C0A1DBF9FC6FCB2CF80A0129092F698A764E456E04487F682D2ABBE/8a589401da4a42ea8c783cc7de9318ea/stp/media/536a7752160649139ba057c99c88c459/Clamping-element-MK6501A-Rollco.stp 63 90 0 138 49 27 90 63 30 5 30 9,50 M10 15 5 7 M5 37 32 30
